Product Features

• Integrated Woofer/baffle Design Delivers Greater Low Frequency Response By Employing A Larger 7" Woofer Where Competitive Models Of The Same Outer Size Employ Only 6 1/2" Woofers In The Same Size Speaker Installation
• Polypropylene Cone Is Light, Strong And Well Damped To Provide "best In Class" Bass Response
• Treated Urethane Surround Increases Sensitivity While Preserving Durability
• 13mm Kaladex Tweeter With Fluid Cooling Provides Wide Dispersion For Clear And Detailed High Frequencies
• Magnetically Attached, Rust-resistant Grille Covers Install Quickly And Provide A Low Profile Look
• Weather Resistant Construction Reduces Installation Limitations And Provides Unique Solutions In Moist Environments Or Outdoors Under Eaves

Specifications

• Recommended Amplifier Power: 10 To 75 Watts
• Impedance: 8 Ohm Nominal; 6 Ohm Minimum
• Frequency Response: 58Hz To 20kHz /-3dB
• Voice Coil Size: 3/4"
• Frame Dimensions: 9 7/8" (25.1 Cm)
• Hole Cutout Dimensions: 8 1/2" (21.6 Cm)
• Depth Behind Ceiling (5/8" Drywall): 3 3/4" (9.5 Cm)
• Shipping Weight: 4.2 Lbs (1.9 Kg)

Warranty

• Lifetime Limited Warranty
