The Triplett LVPRO is an industry leading cable tester that runs a variety of cable testing procedures such as wiremap, timing tests (delay, skew), impedance measurement, Ethernet switch port blink, speaker pop, cable length, PoE volts, loaded battery test and 10/100/1000 indication, plus it gives you the ability to store and print up to 250 test reports.
DESCRIPTION
The Triplett LVPRO is an industry leading cable tester that runs a variety of cable testing procedures such as wiremap, timing tests (delay, skew), impedance measurement, Ethernet switch port blink, speaker pop, cable length, PoE volts, loaded battery test and 10/100/1000 indication, plus it gives you the ability to store and print up to 250 test reports. Three models to choose from. Model LVPRO20 has 7 test apps and is Web upgradeable to Model LVPRO30 which has 13 test apps. Model LVPRO30SR adds Smart Remotes to Model LVPRO30. The LVPRO comes complete with Detachable Remote, F Male to BNC Male, F Male to BNC Female, (2) RJ45 patch cables, RJ45 to alligator clip adapter, USB cable, (4) AA batteries and carrying case. Models 30 and 30SR also include: 10 RJ45 remotes, 10 Coax remotes, and 3 RLQ adapters. In addition, Model 30SR includes Smart Remotes.
CATEGORY:
Features
- Works with virtually all cable types including speaker cable, coax, alarm cable and Category cable (CAT5,6). If you have a unique cable, the LVPro has adjustable VOP, a technology that allows the LVPro to be tuned to your cable
- Perform detailed wiremap, measure cable distance to open or short, test coax and RJ11 cables for faults
- Check line voltage on RJ45 (PoE) and telephone lines, measure incoming data speed, store and print up to 250 Reports (Model 30 or higher)
- Test modules available with additional features, Web upgradeable using the LVPro Manager software and included USB cable
Overview
Triplett LVPRO30 Upgradeable Cable Tester
- Test modules available for additional features, e.g Video Test Module
- Perform detailed wire map
- Store up to 250 printable reports
- Measure cable length and distance to open or short
- Check line voltage on RJ45 (PoE) and telephone lines
- Measure incoming data speed 10/100/1000
- Test Coax and RJ11 cables for faults
- Load test batteries
- Backlit display
- Detachable remote
- 1 year warranty
With 12 Tester Apps for all Wire Types (COAX, CAT5/5e/6/6a/7, Shielded/Unshielded)
The LVPRO Series from Triplett is the tool that does it all! This industry leading cable tester is the one tester you need to run a variety of cable testing procedures including Cable Map, Ethernet Switch Port Blink, Speaker Pop, Cable Length, PoE Volts*, Battery Test, and 10/100/1000 indication*, with the ability to print results*. The LVPRO allows you be the pro in any cable testing situation. The series includes three models, the LVPRO20, LVPRO30, and LVPRO30SR. Each model is upgradable with a growing list of tester apps. The LVPRO20 is preloaded with a powerful cable testing pack and 6 device testing apps, plus Length Return Loss Quality (RLQ) Pack Apps, Alert LEDs to indicate POE, Tone Locator, Port Blink, Speaker Pop, Speaker 7.1 ID and Wall Jack ID (must be purchased separately for LVPro20 and LVPro30). It also includes RJ45/ Alligator Clip adapters, patch cable, 9V battery, and zippered, embroidered pouch. *On 30 & 30SR models only.
The LVPRO30 comes with all the same features as the LVPRO20, but it comes preloaded with 6 additional tester apps, for a total of 12. The LVPRO30 also includes 10/100/1000 detection, PoE volts, phone volts, CCTV signal, battery load test, 10 RJ45 ID's, 10 COAX ID’s, and the ability to print test results (Stores up to 250 Reports). The final model in the series, the LVPROSR, is the LVPRO30 feature pack plus RJ45 Smart Remotes (8-pieces). In addition, all of these models have a backlit screen and can be expanded with Triplett's new Test Modules that increase the form and function of an already powerful device.
|
|
|
|
|
|---|---|---|---|
Loaded Battery TestTest alarm system and other backup batteries by placing a 350ma load on the battery during the test. |
Port Blink Cable DetectionLocate a cable connection to a switch port by blinking the switch's Link LED. |
PoE/PairsDetect PoE voltage and display its amplitude and location on the cable, midspan, endspan, or both. |
CCTV/Vpp (Peak to Peak Voltage)CCTV systems require a minimum Vpp to properly DVR. Measure and display Vpp of the video signal. |
|
|
|
|
|
|---|---|---|---|
10/100/1000 Detection/DisplayPlug into any active port on a computer, switch, VoIP, or access point and display its data capabilities. |
Alert LEDsDetect Link pulses from network devices and volts from voltage-oriented tests. |
LVPro Manager Software PrintingStore up to 250 tests of all cable types for printing. USB Cable and software are included. |
| Cable Test Pack (All Types) and Length Pack | ✓ | ✓ | ✓ |
|---|---|---|---|
| Wall Jack ID | ✓ | ✓ | ✓ |
| Speaker Popper and Speaker 7.1 ID# Mapper | ✓ | ✓ | ✓ |
| Tone Cable Detection and Return Loss Quality | ✓ | ✓ | ✓ |
| Port Blink Cable Detection and Alert LEDS (Links, Volts) | ✓ | ✓ | ✓ |
| 10/100/1000 Detection/Display | ✓ | ✓ | |
| PoE/Pairs, Phone, and Loaded Battery Tests | ✓ | ✓ | |
| CCTV/Vpp (peak to peak voltage) | ✓ | ✓ | |
| Print Up to 250 Reports | ✓ | ✓ | |
| 8 Smart Remotes | ✓ |
Specifications
| Cable Types Tested (All LVPRO models) |
Shielded and unshielded twisted pair. All cable categories Coax. All types Telephone, speaker and alarm wire |
| Cable Tests (All LVPRO models) |
Opens, shorts, reversals, split pairs, wiremap, propagation delay,skew, ohms. Feet and metricselectable |
| Advanced Cable Tests (All LVPRO models) |
Length and distance to fault Adjustable and standard VOP settings for accurate length of all cables RLQ (Return Loss Quality) |
| Locating cable ends, split wires and switch ports (Al LVPRO models) |
Wall jack identifiers (RJ45, coax, and mixed kits available) Speaker identification (Qty 8 available separately) Port blink. LVPRO lights the LED on the port switch |
| Device Tests (All LVPRO models) |
Speakers: audible popper |
| Voltage Protection (All LVPRO models) |
DC Volts: 100V AC Volts: 70 |
| Length Measurement (All LVPRO models) |
Max (all wire types): 1000 feet (305m) Min split pairs: 6 feet (2m) Min RLQ: 20 feet (7m) VOP calibration:Min cable sample 150 feet (50m) |
| Upgradeable (Model 20) |
Length and distance to fault Adjustable and standard VOP settings for accurate length of all cables RLQ (Return Loss Quality) |
| Network Devices (Models 30 and 30SR) |
10/100/1000 advertised speed and cable pairs used PoE pairs and cable pairs used CCTV camera video signal: measure peak to peak volts CATV (cable TV) requires min 30mV peak to peak signal Battery test:100mA loaded test for 12V alarm and other batteries |
| Printed Reports Models 30 and 30SR | Stores 250 cable test reports in memory |
| Battery | Type: 4 AA alkaline Life: 24 to 30 hours Auto power off: 30 minutes |
| Backlit Display | Off and 2 brightness levels |
Includes
- Detachable Remote
- F Male to BNC Male
- F Male to BNC Female
- (2) RJ45 patch cables
- RJ45 to alligator clip adapter
- USB cable
- (4) AA batteries and carrying case
Downloads
FAQs
-
Q. Does the LVPRO Series test LAN cables to ANSI/TIA 568-B.2-10 standards?
A. The LVPRO series does not test to the ANSI/TIA standard. The unit tests continuity, length, delay, skew, and impedance.
